NanoSuit Solution Type I for microorganisms and wet tissues – 5mL


For the observation of living organisms and wet samples under an electron microscope: the NanoSuitⓇ Type I for microorganisms, small organisms and small biological wet tissues

SKU: 7701 Research Area: Applications:


“Taking electron microscope images of biological objects in their natural state.”
The NanoSuit solution I was developed for observing samples such as microorganisms and small organisms by a conventional scanning electron microscope. The biocompatible polymers contained in this solution polymerizes by electron beam under the conditions of electron microscopic observation. The polymers form a film on the sample surface, which suppresses the evaporation of water from the sample.
●A novel technology enables us to observe cells, microorganisms, etc. in a living state using scanning electron microscopy (SEM).
●“NanoSuit” forms a very thin barrier layer on the surface of an object and the barrier layer holds moisture in the object under vacuum condition in electron microscopy. Also, the barrier layer is electrically conductive.
●“NanoSuit” makes it possible to observe biological objects with their natural image texture.
●”NanoSuit” is very easy to use. Only dropping the “NanoSuitsolution” onto the objects, then you can observe the objects using SEM.

Title Type Size
TypeI_Datasheet application/pdf 251 KB
TypeI_SDS application/pdf 94 KB
